original source : https://youtu.be/wtnjhbt6ipg


compile "android.arch.persistence.room:runtime:1.0.0-alpha3"annotationProcessor "android.arch.persistence.room:compiler:1.0.0-alpha3"compile 'com.google.code.gson:gson:2.6.2'
First 2 lines for including Room DB in our project and 3rd one is Gson which we will use to convert our object to String.
Our modified User.java looks something like this. Even though you can’t see any getter or setter method here, you need to include them or make the fields public for Room to access it.
User.java
@Entitypublic class User { @PrimaryKey private int uId; private String uName; private ArrayList<String> uPets = new ArrayList<>(); public User() { } public User(int id, String name, List<String> pets){ this.uId = id; this.uName = name; this.uPets.addAll(pets); }; //getters setters removed for brevity}
User DAO stays more or less the same. You can include methods to fetch particular user from user id or name, I will leave that as an exercise for you.
UserDAO.java
@Daopublic interface UserDAO { @Insert(onConflict = REPLACE) void insertUser(User user); @Query("SELECT * FROM User") List<User> getUsers(); //include any methods to fetch specific user // @Query("SELECT * FROM User")}
And our UserDB will also stay the same except small difference.
UserDB.java
@Database (entities = {User.class},version = 1)@TypeConverters({Converters.class})
public abstract class UserDB extends RoomDatabase { public abstract UserDAO userDAO();}
Noticed that @TypeConverters annotation we provided along with @Database annotation, this will be the class which will tell Room how to convert ArrayList object to one of SQLite data type. We will implement methods to convert ArrayList to String for storing it in DB and String back to ArrayList for getting back original User object.
Type Converter specifies additional type converters that Room can use. The TypeConverter is added to the scope of the element so if you put it on a class / interface, all methods / fields in that class will be able to use the converters.
Without further delay, we will see how our type converter looks in our case.
UserDAO.java
public class Converters { @TypeConverter public static ArrayList<String> fromString(String value) { Type listType = new TypeToken<ArrayList<String>>() {}.getType(); return new Gson().fromJson(value, listType); } @TypeConverter public static String fromArrayLisr(ArrayList<String> list) { Gson gson = new Gson(); String json = gson.toJson(list); return json; }}
As you can see, we have 2 methods in TypeConverter.
.
.
.
.
참고사항) @Bindable 에 대하여
.
.
.
.
.
.
.
.
.
.
.
.
DAO 만들기
.
.
.
.
database 만들기
.
.
.
.
allowMainThreadQueries()를 통해 메인쓰레드에서도 query가 작동가능하게 된다.
본래는 다른 thread에서 해줘야 한다.
.
.
.
.
onCreate() 데이터베이스가 생성될때 호출된다.
onOpen()은 데이터베이스가 열릴때 호출된다
.
.
.
.
.
.
10분분량 개념잡기 좋다.
.
.
.
.
.
아래는 coroutines사용을 위해 suspend를 추가한 모습
이 개발자는 기본 Fragment를 extend해서 coroutine의 기능을 추가하고 이를 모든 fragment에 사용하려고 한다.
아래는 Context를 extension func 추가 해서 toast를 쉽게 하는 팁설명
.
.
.
.
.
.
.
.
.
참고사항)
room sqlite에 primitive 타입이 아닌 다른 데이터를 저장해야 하는 경우 (obj를 json string으로 변경해서 sqlite database에 저장한다.)
androidTest는 android component관련 테스트할때 사용한다.
일반 java, kotiln 테스트는 test를 이용한다.
.
.
필요한 dependencies
.
.
원본 소스 코드 (테스트될 코드)
.
.
오른쪽 클릭
.
.
JUnit4가 안드로이드와 더 잘 작동 (2020 기준)
.
.
.
.
테스트 코드
https://www.youtube.com/playlist?list=PLIUuxxIJtMjWR77V4_QbKZY0gZb1kzoJ8
android가 어떻게 구성되어 있는지 좀더 깊이 설명하는 강좌
android official docs : https://developer.android.com/guide/topics/connectivity/usb/host
In general, you obtain a UsbManager
to retrieve the desired UsbDevice
. When you have the device, you need to find the appropriate UsbInterface
and the UsbEndpoint
of that interface to communicate on. Once you obtain the correct endpoint, open a UsbDeviceConnection
to communicate with the USB device.
usb지원은 API Level 12 or higher
<uses-feature>
element that declares that your application uses the android.hardware.usb.host
feature.(이것은 기본적으로 항상 넣어야 하는 내용이다)<intent-filter>
and <meta-data>
element pair for the android.hardware.usb.action.USB_DEVICE_ATTACHED
intent in your main activity. The <meta-data>
element points to an external XML resource file that declares identifying information about the device that you want to detect.In the XML resource file, declare <usb-device>
elements for the USB devices that you want to filter. The following list describes the attributes of <usb-device>
. In general, use vendor and product ID if you want to filter for a specific device and use class, subclass, and protocol if you want to filter for a group of USB devices, such as mass storage devices or digital cameras. You can specify none or all of these attributes. Specifying no attributes matches every USB device, so only do this if your application requires it:vendor-id
product-id
class
subclass
protocol
(device or interface)Save the resource file in the res/xml/
directory. The resource file name (without the .xml extension) must be the same as the one you specified in the <meta-data>
element. The format for the XML resource file is in the example below.AndroidManifest.xml의 예시
<manifest ...>
<uses-feature android:name="android.hardware.usb.host" />
<uses-sdk android:minSdkVersion="12" />
...
<application>
<activity ...>
...
<intent-filter>
<action android:name="android.hardware.usb.action.USB_DEVICE_ATTACHED" />
</intent-filter>
<meta-data android:name="android.hardware.usb.action.USB_DEVICE_ATTACHED"
android:resource="@xml/device_filter" />
</activity>
</application>
</manifest>
res/xml/device_filter.xml 의 예시
<?xml version="1.0" encoding="utf-8"?>
<resources>
<usb-device vendor-id="1234" product-id="5678" class="255" subclass="66" protocol="1" />
</resources>
.
.
.
1번과정 discover하는 방법은 두가지가 있다.
– Use an intent filter
– Enumerate devices
.
.
<activity ...>
...
<intent-filter>
<action android:name="android.hardware.usb.action.USB_DEVICE_ATTACHED" />
</intent-filter>
<meta-data android:name="android.hardware.usb.action.USB_DEVICE_ATTACHED"
android:resource="@xml/device_filter" />
</activity>
<?xml version="1.0" encoding="utf-8"?>
<resources>
<usb-device vendor-id="1234" product-id="5678" />
</resources>
val device: UsbDevice? = intent.getParcelableExtra(UsbManager.EXTRA_DEVICE)
.
.
val manager = getSystemService(Context.USB_SERVICE) as UsbManager
…
val deviceList = manager.getDeviceList()
val device = deviceList.get(“deviceName”)
val manager = getSystemService(Context.USB_SERVICE) as UsbManager
..
val deviceList: HashMap<String, UsbDevice> = manager.deviceList
deviceList.values.forEach { device ->
//your code
}
.
.
.
.
Note: If your application uses an intent filter(위에서 첫번째방법을 사용하는 경우) to discover USB devices as they’re connected, it automatically receives permission if the user allows your application to handle the intent. If not, you must request permission explicitly in your application before connecting to the device.
https://stackoverflow.com/questions/14111353/android-bluetooth-printing/53922171#53922171
https://developer.android.com/training/printing
https://stackoverflow.com/questions/43462836/android-print-to-any-bluetooth-printer
https://www.androidcode.ninja/android-bluetooth-tutorial/
https://stackoverflow.com/questions/14796422/how-to-send-data-to-bluetooth-printer-via-android-app
